The Geometry of Diffraction: Why Cabinet Radii Matter

When an acoustic transducer emits a wavefront across a flat planar baffle, sound propagates hemispherically until it reaches the physical boundary of the enclosure. At this sharp mechanical discontinuity, a sudden pressure drop occurs.

Rather than simply passing into free space, this transition point behaves according to Huygens’ Principle as an independent secondary acoustic source. This secondary emission radiates energy back toward the listener with a phase delay proportional to the physical distance from the driver center to the cabinet edge.

The Physics of Boundary Discontinuity

The audible consequence of boundary diffraction is not subtle. It introduces comb filtering—periodic peaks and cancellations throughout the midrange and lower treble spectrum—which distorts instrument timber and smears localization cues in the stereophonic field.

Many traditional loudspeaker designs attempt to correct for edge diffraction using passive crossover equalisation. This is fundamentally flawed: electrical crossover filters are linear and time-invariant, while diffraction is a spatial, angle-dependent phenomenon. Equalising the on-axis diffraction peak invariably creates an inverse aberration off-axis.

Frequency-Dependent Secondary Sources

Diffraction severity depends directly on the relationship between baffle dimensions and the acoustic wavelength ($\lambda = c / f$):

1. High Frequencies ($\lambda \ll$ Baffle Width): The driver radiates in half-space ($2\pi$ steradians); sound does not effectively reach the distant cabinet edges before attenuating.
2. Transition Region ($\lambda \approx$ Baffle Width): Critical diffraction occurs. The edge generates strong in-phase and out-of-phase reflections, manifesting as sharp $\pm 3\text{ dB}$ frequency ripples.
3. Low Frequencies ($\lambda \gg$ Baffle Width): The enclosure ceases to support the wavefront; radiation transitions seamlessly into full space ($4\pi$ steradians), resulting in the classic $-6\text{ dB}$ baffle step loss.

Measuring Baffle Step Transitions

In our laboratory testing, we utilize gated far-field impulse measurements in conjunction with near-field microphone placement to isolate pure cabinet edge interference from room reflections.

Measurement setup:
- Microphone: Earthworks M30 calibrated pressure transducer
- Distance: 2.0 meters on-axis
- Time gate: 4.8 ms (anechoic simulation cutoff)
- Signal: 256k Logarithmic Sine Sweep

When analyzing the impulse response of a standard 90-degree squared cabinet baffle, secondary high-frequency ripple artifacts appear distinctly between 0.8 ms and 1.6 ms following the primary acoustic arrival.

Real-World Impulse vs. Anechoic Simulation

Computer simulations frequently assume an idealized rigid edge boundary. In practice, boundary impedance variations and boundary layer air turbulence further complicate the radiation pattern. A sharp bevel or chamfer merely splits the single diffraction peak into two smaller, higher-frequency secondary ripples, shifting the problem without resolving it.

Saphyr’s Continuous Tangent Curvature

To eliminate secondary radiation without introducing phase anomalies, Saphyr utilizes a continuously varying elliptical curvature profile across the front baffle edges.

By ensuring that the radius of curvature exceeds one-quarter wavelength of the lowest diffraction frequency, the wavefront smoothly wraps around the enclosure without encountering a sudden acoustic impedance mismatch:

• Zero sharp boundary transitions: The acoustic wavefront expands smoothly into three-dimensional space.
• Preserved time-domain coherence: Energy arrives strictly from the primary radiating diaphragm.
• Micro-detail transparency: Complex acoustic cues such as room reverberation tails and instrument decay remain pristinely separated.

Conclusion: Physics Over Cosmetic Sculpting

Loudspeaker enclosure geometry is not a matter of industrial styling or decorative flair. Every millimeter of contour either serves the laws of fluid dynamics and acoustic wave propagation or degrades them.

At Saphyr, our Reference Models are built around this non-negotiable principle: rigorous physical mathematics guide the form, and meticulous human hands execute it.
